Introduction

So you've finished (UCLA) CS32, and know basic C++, data structures, and all that. But it stops there. Nobody really teaches more about C++. Everyone tells you that "C++ is very fast, but it's very tedious", or "C++ is fast only if you know how to make it fast", but they don't really tell you how to make it fast.

But that's not really the curriculums fault, the purpose of those introductory CS classes is to get students to master basic programming concepts and learn the fundamentals of object-oriented programming. C++ just happens to be the language that UCLA has chosen to teach in. After CS31 and CS32, UCLA students rarely get the opportunity to program in C++, with the majorty of classes favoring other imperative programming languages over C++ like Java, Python, and C.

But not to worry, this blog will attempt to give you a killer introduction on how move semantics work in C++. Even though the term sounds scary, it's really just another way that C++ programmers can make their programs even faster.

The Opening Problem:

Let's say that you're a rookie software engineer that works at MADE entertainment, a Korean entertainment company. Your manager wants you to write a program that reports the company's data on its actors and singers. Moreover, since this program is going to be called multiple times by internal systems and displayed on the company website, performance is of the utmost importance.

Naively, you choose C++ to write your program, and naively, you write the following program:

std::vector<std::string> build_vector(dbConnection db) {
    std::vector<std::string> vec;
    // fill the vector with thousands of entries
    return vec;  // vec is copied here
}

void report_statistics() {
    std::vector<std::string> data;

    data = build_vector(singers_db);  // the return value is copied and assigned to data
    //  report singer statistics

    data = build_vector(actors_db);  // the return value is copied and assigned to data
    // report actor statistics
}

Oh no! This code seems fine, but you forgot that due to certain legacy code remaining in the codebase, MADE Entertainment systems still run on C++98. In which case, your code is super inefficient. Why? Because for every call to build_vector, we are first filling a vector with thousands of entries, and then copying it twice.

• We copy the vector once when we return from the build_vector function. Because vec is a local variable that we then return in our function, since vec will soon go away, C++ will copy the data and then return it back to the calling function
• We copy the vector another time when we assign the return vector that we just copied into data. This is because the return values of functions are also treated as temporary variables, which means that C++ will copy the data again, and then have data refer to that new copied data.

An animated representation of the above looks like the following:

Hence, we see that although the code that you wrote looks pretty intuitive, it is actually very inefficient. Your manager would probably tell you to change your code to use pointers instead to avoid the uncessary copying. However, jokes on him because in C++11, the code that you wrote is perfectly valid and will result in 0 copying of the vector that you created.

Why?

Because C++ 11 introduced move semantics, which, instead of copying data, the compiler will realize that we are copying data unnecessarily, and will instead move the vector from one variable to another.

Below is an animated representation of what 'moving' looks like:

Hence, as we can see, even though we created the vector and filled its contents in a local function scope, we were still able to access that vector without needing to copy the data; we just made data refer to that vector instead. Essentially, we 'moved' the original vector from one place to another. And that is, the main philosophy behind move semantics.

Aha! Maybe now you can use reverse uno card and flex your C++ knowledge on your manager and tell him to upgrade the system to C++11 instead.

Don't do this though

But what is going on behind the scenes? What's the theory behind this all? Well to first understand the theory, we will first introduce lvalues and rvalues in C++.

Introducing rvalues and lvalues in C++

lvalues

An lvalue is roughly something that:

• can appear on the left side of an assignment
• has a name
• has an adress

Using these rough definitions, some examples of lvalues might look like:

int x = 10;
const std::string hello = "konnichiwa";
std::string hi = "annyeong";

In these assigment expressions, x, hello, and hi are all lvalues: they have a name and address, and they appear on the left side of an assignment.

lvalues are not only variable names though. They can sometimes be expressions too:

std::vector<int> numbers = {1, 2, 3};
numbers[2]; // this is an lvalue
*(numbers + 2); // this is also an lvalue

We see here that even applying certain in operators on lvalues in certain situation can still result in an lvalue.

rvalues

An rvalue is roughly, something that is not an lvalue:

• Temporary objects
• Literal constants
• Function return values (that aren't lvalue references)
• Results of built-in operators (that aren't lvalues)

rvalues generally have a short lifetime

Hence, some examples include:

28; // an rvalue

std::string bye() {
    return "jal gayo";
}

bye(); // an rvalue
numbers.size(); // an rvalue
3 + 2; // an rvalue

References

If you've taken CS31/32, you'll know that we can take references of a variable in C++; it's how pass by reference works. Well in fact, we can take the reference to not just variables, but lvalues, and the syntax is exactly the same: with the & sign.

int& r0 = hello; // okay, variable is an lvalue
int& r1 = numbers[2]; // okay, array subscript is an lvalue

int& r2 = 1 + 2; // error, this is an rvalue

It should be noted though, that we can bind a const lvalue reference to anything, eg.

const int& r3 = 1 + 2; // okay to bind to an rvalue

On the other hand, we can actually take the reference of rvalues as well. We represent this using the double ampersand sign: && in the declarator.

One difference with the single &, is that we can ONLY bind this to rvalues.

For example, if we had a function add:

int add(int&& x, int&& y);

int IU_age = 28;
int one = 1;
add(IU_age, one); // wrong, cannot pass in lvalues

add(28, 1); // ok, passed in two rvalues

It is important to note that the usage of an rvalue reference is an lvalue

int addone(int&& z) {
    add(z, 1); // wrong, z is now used as an lvalue
}

addone(2); // ok, passed in an rvalue

std::move

One function that's very important to us that was introduced in the standard library is the std::move function.

You can look at the documentation for more details about the function, but essentially, it does one simple thing: It is a cast that produces an rvalue reference to an object, or to be more accurate, it turns the object into an xvalue (a type of rvalue, it stands for "eXpiring value"). It doesn't actually move anything, all it does is signal to the compiler that:

You can do anything to me, move or destroy any of the resources I am holding or use it elsewhere since I am going to be destroyed soon anyways.

Often times, the most useful situation is when we want to turn an lvalue into an xvalue so that we can pass it in to a function that expects rvalue args.

Going back to our previous example:

int add(int&& x, int&& y);

int IU_age = 28;
int one = 1;
add(IU_age, one); // wrong, cannot pass in lvalues

add(28, 1); // ok, passed in two rvalues

add(std::move(IU_age), std::move(one)); // ok, passed in an rvalue

std::cout << IU_age; // wrong!!! Do not use a variable after it has been std::move'd

As we can see, once we std::move the lvalues, they can then be passed into our add function that expects only rvalues.

Important note: DO NOT use a variable after std::move has been called on it. This is undefined behaviour because the compiler could have done anything it wanted to do to that object.

Move Constructor and Assignment

Ok, so how does move semantics work? Well, move semantics allows an object, under certain conditions, to take ownership of the resources of another object.

Armed with the knowledge of rvalue and rvalue references, we can look at one useful application of it: move constructors

Move Constructor

As it's name suggests, move constructors simply transfer ownership of a managed resource into the current object.

Why do we want to do this? Well let's take a look at the following example.

class Idol {
    int age;
    std::string name;
    Idol(int age, std::string name); // normal constructor
    Idol(const Idol& other) :        // copy constructor
        age(other.age)
        name(other.name)
    {}
};

Now, the interesting part is in the copy constructor. What if, for some reason, we wanted to do something like this:

Idol return_IU() {
    Idol iu = Idol(28, "IU");
    return iu;
}

Idol IU(return_IU()); // copy constructor invoked

Here, the copy constructor is invoked because tried to pass in another Idol object (return_IU()), into the constructor. But what do we notice about the Idol object returned by return_IU()? It's an rvalue! Moreover, we notice that the Idol object returned by return_IU() will immediately go away/destroyed after the line ends. So then why are we copying, when we can just have our new IU object take ownership of the resources owned by the temporary Idol object returned by return_IU()?

That is the purpose of move constructors, and in practice, it could look something like this:

class Idol {
    int age;
    std::string name;
    Idol(int age, std::string name); // normal constructor
    Idol(const Idol& other) :        // copy constructor
        age(other.age),  // copies this int
        name(other.name) // copies this string
    {}
    Idol(Idol&& other) noexcept :   // move constructor
        age(std::move(other.age)),   // does not copy the int
        name(std::move(other.name))  // does not copy the string
    {}
};

Here, all the move constructor does, is simply call the int move constructor for age, and the std::string move constructor for name. Notice that the way we did this, was to call std::move to turn other.age and other.name (recall that we should now treat these like lvalues) into rvalues, which will overload and invoke the move constructors for int and std::string.

Note: For primitive types like int, float, double, a move is the same as copying the bits, which means that even though I invoked the move constructor for age, all it does is copy the int. The reason why I move the int is just for demonstration purposes. This is true for all future instances where I try to 'move' a primitive type.

Generally, a move constructor will:

• Transfer ownership of resources from existing objects to object being constructed
• Use subobject's move constructor when possible
• Explicit transfer of resources otherwise (eg. with pointers and file descriptors etc, where you are responsible for allocating and deallocating the member variables)

Now, when we call:

Idol IU(return_IU()); // move constructor invoked

We will invoke the move constructor, which means that the IU object now contains the 'stolen' resources that were once owned by the temporary object returned by return_IU().

Note that whenever we call the move constructor, the original object will be left in an invalid state and we should not use that object anymore. In our case, since the temporary object will be deleted immediately after this line, it doesn't concern us.

Move assignment

Very similar to move constructor, a move assignment does the same thing, but with the assignment operator instead.

The goal of the move assignment is to free the resources owned by the assigned-to object, and transfer the ownership of resources from assigned-from object to assigned-to object. Again, we should use a subobject's move assignment operator when possible.

Going back to our Idol class:

class Idol {
    int age;
    std::string name;
    Idol& operator=(const Idol& other) {     // copy assignment
        age = other.age; // copies this int
        name = other.name; // copies this string
        return *this;
    }
    Idol& operator=(Idol&& other) noexcept { // move assignment
        age = std::move(other.age);  // does not copy the int
        name = std::move(other.name); // does not copy the string
        return *this;
    }
};

Again, with the move assignment operator, we just overload the assignment operator to expect an argument of type rvalue reference, and then we go with convention to invoke the move assignment operators of our member variables. This way, whenever we do assignment from a rvalue, it's resources will get moved rather than copied, which is much more efficient.

Idol IU = Idol(28, "IU");
Idol IU2 = Idol(28, "Lee Ji Eun");
IU2 = IU; // copy assignment operator invoked
IU2 = Idol(28, "Cindy"); // move assignment operator invoked

// or

IU2 = std::move(IU); // move assignment operator invoked
// DO NOT use IU after this

Back to the Opening Problem

With our knowledge of move assignments and move constructors, we can understand now, why our original 'naive' code in C++98 is actually just as efficient in C++11.

std::vector<std::string> build_vector(dbConnection db) {
    std::vector<std::string> vec;
    // fill the vector with thousands of entries
    return vec;   // move constructor called

}

void report_statistics() {
    std::vector<std::string> data;
    dbConnection singers_db;
    dbConnection actors_db;

    data = build_vector(singers_db);  // move assignment operator called
    // This is because the return value of functions is treated like an rvalue
    // So no need std::move

    //  report singer statistics

    data = build_vector(actors_db);  // move assignment operator called


    // report actor statistics

We see that instead of having two copies, we instead invoke the move constructor and move assignment operators.

In the line:

return vec;

Instead of calling the copy constructor, since the standard library of C++ has defined a move constructor for std::vector, then since vec is a local variable that is the return value expression, it is treated like a rvalue, and hence the move constructor is called instead of the copy constructor. We didn't even need to use std::move.

Now in the lines:

data = build_vector(singers_db);
data = build_vector(actors_db);

Instead of calling the copy assignment operator, since the standard library of C++ has defined a move assignment operator for std::vector, then since the return value of functions are treated like ravlues, then it means that the move assignemnt operator is called instead.

Hah!

Another common pattern

Often times, it is not just copy constructors and move assignments that we can use move semantics. Another very common use of this kind of overloading using move semantics is in STL containers.

For example, std::vector<T>::push_back has two overloads.

void push_back(const T& value);
void push_back(T&& value);

This means that if we did:

std::vector<string> v;
std::string str = "Hello";

std::string bye() {
    return "bye";
}

v.push_back(str); // copy

v.push_back(bye()); // move

Similar with the move constructors, when we call push_back on an lvalue, the string is copied. But for rvalues and xvalues, the compiler knows that you don't need it anymore and it can do whatever it wants with it; the second overloaded push_back function is called where the data is moved instead.

Note that you can do this to an lvalue like str, but we must use the std::move function to do the move.

v.push_back(std::move(str)); // move

This is actually a very common thing to do. If str is an extremely large string, and we know that we are actually done with str after we push it back into the vector, then we can just move the data held by str instead of copying it.

Conclusion

The applications of move semantics don't end here! All I introduced here today was how move semantics can turn expensive copies into cheap moves. There are many other places where move semantics is useful eg. implementing 'move-only' types, perfect forwarding etc. But that will not be discussed here.

I just want to conclude by reiterating the fact that in CS31 and CS32 (or any intro CS class taught in C++), the C++ that they teach is very very old. Since then, many new features have come out and have made C++ much more versatile and easier to write code in.

This is not only true for C++, but for any programming language that you learn, so it's important to keep learning and keep being in touch with new language updates. Admittedly, I am not that best at doing this as well, so I think it's a work in progress for all of us.

If you've made it to end, as always, thank you for reading and looking at my memes.
